Speaker Sizes
| Dash |
3.5" |
| Front Doors |
6.75" (6.5" w/ Adapter) |
| Rear Deck |
6"x9" |
Black Connector
| Antenna |
Dark Green/Red |
| Speaker + Left Rear |
Brown/Yellow |
| Speaker + Right Rear |
Blue/White |
| Speaker + Left Front |
Dark Green |
| Speaker + Right Front |
Violet |
| Speaker - Left Rear |
Brown/Light Blue |
| Speaker - Right Rear |
Dark Blue/Orange |
Gray Connector
| Ground |
Black |
| Speaker - Left Front |
Brown/Red |
| Speaker - Right Front |
Dark Blue/Red |
| Dimmer |
Black/Yellow |
| Illumination |
Orange |
| 12V + Switched |
Red/White |
| 12V + Constant |
Pink |
|
